Alpha 3D Scanner L

Datasheet

Parameter	Value
3D Sensing Technology	Structured Light
Output data	3D points (x y z) Normals (x y z) Depth Map (z) Texture (grayscale intensity) Confidence
Resolution	1.5 Million 3D Points (1440 x 1080)
Scanning range	870 - 2150 mm
Optimal scanning distance	1245 mm
Scanning area at sweet spot	1091 x 761 mm
Point-to-point distance (at sweet spot)	0.82 mm
Calibration accuracy (1 σ)	0.50 mm
Temporal noise (1 σ)	0.45 mm
Scanning time	from 450 ms
Dimensions	86 x 68 x 428 mm
Baseline	350.0 mm
Weight	950 g
Temperature working range	Full: 0 - 40 degrees Optimal: 20 - 25 degrees
Power	PoE or 24V
Data connection	1 Gbit Ethernet
